REF5025IDGKR Voltage Reference IC Fixed 2.5V V ±0.05% 10 mA 8-VSSOP

Brand Name : Original

Model Number : REF5025IDGKR

Certification : Original

Place of Origin : Original

MOQ : 1

Price : negotiation

Payment Terms : T/T

Supply Ability : 100,000

Delivery Time : 1-3working days

Packaging Details : carton box

Voltage - Output (Min/Fixed) : 2.5V

Current - Output : 10 mA

Tolerance : ±0.05%

Current - Input Bias : 5 pA

Temperature Coefficient : 3ppm/°C

Noise - 0.1Hz to 10Hz : 7.5µVpp/V

Voltage - Input : 2.7V ~ 18V

Contact Now

REF5025IDGKR Voltage Reference IC Fixed 2.5V V ±0.05% 10 mA 8-VSSOP

Series Voltage Reference IC Fixed 2.5V V ±0.05% 10 mA 8-VSSOP

Features of REF5025IDGKR

FET input: IB = 50 pA Maximum FET input: IB = 50 pA Maximum • Low temperature drift:
– High-grade: 3 ppm/°C (maximum)
– Standard-grade: 8 ppm/°C (maximum)
• High accuracy:
– High-grade: 0.05% (maximum)
– Standard-grade: 0.1% (maximum)
• Low noise: 3 μVPP/V
• Excellent long-term stability:
– 50 ppm/1000 hr (typical) first 1000 hours
(VSSOP)
– 25 ppm/1000 hr (typical) second 2000 hours
(VSSOP)
• High-output current: ±10 mA
• Temperature range: –40°C to 125°C

Product Attributes of REF5025IDGKR
TYPE
DESCRIPTION
Category
Integrated Circuits (ICs)
Power Management (PMIC)
Voltage Reference
Mfr
T I
Series
-
Product Status
Active
Reference Type
Series
Output Type
Fixed
Voltage - Output (Min/Fixed)
2.5V
Current - Output
10 mA
Tolerance
±0.05%
Temperature Coefficient
3ppm/°C
Noise - 0.1Hz to 10Hz
7.5µVpp/V
Noise - 10Hz to 10kHz
-
Voltage - Input
2.7V ~ 18V
Current - Supply
1.2mA
Operating Temperature
-40°C ~ 125°C (TA)
Mounting Type
Surface Mount
Package / Case
8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
Supplier Device Package
8-VSSOP
Base Product Number
REF5025

Applications of REF5025IDGKR

• Precision data acquisition systems
• Semiconductor test equipment
• Industrial process controls
• Medical instrumentation
• Pressure and temperature transmitters
• Lab and field instrumentation

Environmental & Export Classifications of REF5025IDGKR
ATTRIBUTE DESCRIPTION
RoHS Status ROHS3 Compliant
Moisture Sensitivity Level (MSL) 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
